254 MW 1998 Refurbished Siemens TG50 D5 Natural Gas Turbine
BRILLIANT, REFURBISHED 254MW Gas Turbine Power Station. (1998) TWO (2) SIEMENS WESTINGHOUSE W701DS GAS TURBINE GENERATOR SETS (FIAT TG50D5). LOW HOURS and GREAT PRICE for 254MW Package made up of 2 x 127MW GTs reset to zero hours in 2014 by Siemens and Turbocare. Fuels: Natural Gas, HFO and Distillate Oil. This EXCLUSIVE USP&E power station consists of two (2) gas turbines had been originally designed by Westinghouse as W501D and were upgraded by Fiat to W701DS version of it, with an increased output of 9% and higher efficiency of 1.4% over the previous version. The nominal net site output is 127.8 MW at ISO conditions, with 32% efficiency in open cycle and 52% efficiency in combined cycle. The turbines are dual fired both on natural gas and distillate oil (also heavy fuel oil, following pre-treatment) and are equipped with by-pass stacks for simple cycle operation. Each unit is located in a separate enclosure and is equipped with its own inlet filtration system, anti-icing system and water injection for NOx abatement. A warranty for 8,000 hours or 12 months from first fire can be negotiated with Siemens if required. TECHNICAL DETAILS: 2 x Fiat Avio TG50 D5 GAS TURBINE at 127 MW each, 50Hz. Condition: Like new, zero hour overhauled, upgraded to the latest technology from Siemens. Brand new PLC.
GENERATOR: ABB 50WT 18H-66, 140,000 kVA, 15 kV, 0.9 PF, 126,000 kW, 3,000 RPM, Hydrogen Cooling System, ABB Static Exciters, Condition: Overhauled from Alstom.
SCOPE OF SUPPLY: Gas Turbine Package, Generator, PLC (NEW), Control Center, 6 KV Board, Generator protection, Battery charger, Generator Circuit Breaker, Starting system, Cooling water system, Housing, Emergency Diesel Generator, Starting system, Exhaust system, Lube oil system, Air system, Cooling air system, Gas fuel system skid, Liquid fuel system kid, Water injection kit.
Warranty: Yes with turn key installation and service contract 1 or 2 years.
*In addition to this previous maintenance, IPSA contracted TurboCare SpA to conduct major overhaul of both generator assemblies including stator and rotor overhauls. TurboCare SpA also upgraded both gas turbine longitudinal sections to 127.8MW according to the OEM technical specification. The overhaul and upgrade results as well as the aftermath performance test results may be available upon request.
|Fuel type||Natural Gas|
