$7,080,000 (USD)

17.5 MW 2009 New Wartsila 20V34 SG Natural Gas Power Plant

No longer available

Description

USP&E Global hereby presents zero-hour, uninstalled Wartsila 17.5 MW Natural Gas power Plant with 2 x 20V34 SG generators. Power generation:- 2 x 8 730 kW at 11 kV, 50 Hz Hot water (90 °C) production:- 2 x 6450 kW (from 70 to 90 °C) Fuel:- Natural gas Engines:- 2 x W20V34SG, running at 750 rpm Alternators:- 2 x AKV 10913 kVA, 11 kV, 50 Hz, p.f. 0.8 Operating hours:- ZERO Original heat rate (at alt.):- 8124 kJ/kWhe (44.5 %) Plant own consumption:- 389 kW Cooling system:- Closed loop radiators All equipment is intact and is complete with installation & operation manuals, other documentation and spare parts. The generators have the original preservation from the factory, as they are never installed. This complete power plant equipment including building structures is still in original shipment crates. The two Wartsila 20V34 SG natural gas engine driven generators have a total gross electrical output 17.46 MWe at site condition (100 m elevation, temperature 20 °C). The plant has a heat recovery system for hot water production, and it has radiator cooling system for 100 % of heat load. Power plant has advanced Wartsila control and supervision system with centralized Wartsila Operator's Interface System (WOIS). The engines are controlled with Wartsila Engine Control System (WECS). Total shipment includes 2 generating sets, 10 oversized parcels packed on 5 x 40-feet flat track container and 30-35 x 40´ containers. FOR MORE INFORMATION CONTACT US TODAY! info@uspowerco.com

Specifications

ManufacturerWartsila
Model20V34
Year2009
ConditionNew
Stock NumberUSP009196
Wattage17.5 MW
HoursNew!
Fuel typeNatural Gas
Frequency50 Hz
