$10,800,000 (USD)

49.0MW 2009 GE LM6000 PC Natural Gas Power Plant

orCall +1 612-803-8112

Description

49MWe GE LM6000 PC Rated Speed: 3627 RPM Year Manufactured: 2009 EFH: 26.333 hr Package PFH: 30.376 hrs Package PFS: 2.227 Gas Turbine Generator Make and Model: MEIDENSHA 800LL07/EK-AFT 64.500kVA, 11.500V, 3256 A, 3000 RPM, 50Hz Cos ᵠ: 0.8 Insulation Class: F Year Manufactured: 2009 Protection: IP20 Gas Turbine Gearbox Make and Model: FLENDER TX63/1CV Year Manufactured: 2016 52,200 kW, 3,623/3,000 RPM STG Generator Make and Model: SIEMENS TLII 104/17-15 26,500kVA, 11,000V, 1391A, 1500 RPM Cos ᵠ: 0.85 Frequency: 50 Hz Insulation Class: F Year Manufactured: 2001 OTSG Manufacturer: IST Year Manufactured: 2009 HP Pressure: 55.85 Bara HP Heating Surface Area: 15,220 m² HP Steaming Capacity: 43,92 t/h (52,93 Bara and 430°C) LP Pressure: 7.68 Bara LP Heating Surface Area: 5,958 m² LP Steaming Capacity: 14.86 t/h (8.00 Bara and 231°C)

Specifications

ManufacturerGE
ModelLM6000 PC
Year2009
ConditionUsed
Stock NumberUSP009187
Wattage49,000 kW
Hours~26000 Hours
Fuel typeNatural Gas
Frequency50 Hz
